Note:

1.The maximum operating voltage of the motor is 55V. It is recommended that customers add an external capacitor to regulate voltage,

so as to ensure stable battery power supply and protect the PCB from damage caused by voltage fluctuations.

2. If voltage exceeds the rated value,the operating speed must not exceed the motor's rated speed.

* Rated torque testWhen the ambient temperature is 24 degrees Celsius (no other heat dissipation methods),the test is performed

method:

at the rated speed. The motor torque reaches temperature balance under the condition of a temperature rise of 60

degrees Celsius, and the long-term working point is the rated torque value of the motor.
